3000-33113-3020060 Murr Elektronik I/O Systems

Product Details

• Weight
  420 g
• Series
  Field Bus System
• Dimensions H×W×D
  100×45×121 mm
• Switching current per output
  max. 6 A
• Safety contacts (STOP 1)
  max. 250 V AC/6 A; min. 10 V AC/10 mA (resist./ind.), at suitable suppression
• Connection
  Spring clamp plug-in terminals
• PL
  up to e (STOP0); up to d (STOP1)
• Contact material
  Ag Sn O, self cleaning, positively driven
• Service life
  20 years
• Temperature range
  -25...+60 °C (storage temperature -40...+85 °C)
• No. of auxiliary contacts
  1 - (31-32)
• Input voltage
  24 V DC (-15 +20%), 24 V AC (-15 +10%)
• Switching voltage
  max. 250 V AC/DC
• Mech./ elect. life
  10 000 000 switching cycles/load dependent
• No. of safety contacts
  3 - (13-14), (23-24), (33-34), STOP0; 2 - (47-48), (57-58), STOP1
• Input current
  max. 7.1 VA/3.2 W (with monitoring output)
• AC-15
  6 A (230 V AC) STOP0; 3 A (230 V AC) STOP1
• DC-13
  6 A (24 V DC) STOP0; 2 A (24 V DC) STOP1
• Category
  up to 4 (STOP0); up to 3 (STOP1)
• Product article number of manufacturer
  3000-33113-3020060
No. of alarm outputs
3 - (13-14); (23-24); (33-34)
Mounting method
DIN-rail mountable (EN 60715)
Total current (STOP 1)
12 A (45 °C); 10 A (55 °C); 8 A (60 °C)
DC
99% (STOP0); min. 60% (STOP1)
SIL
up to 3 (STOP0); up to 2 (STOP1)
Total current (STOP 0)
18 A (45 °C); 15 A (55 °C); 12 A (60 °C)
Safety contacts (STOP 0)
max. 250 V AC/8 A; min. 10 V AC/10 mA (resist./ind.), at suitable suppression
