MAR-1P-3 Clippard Pneumatic Components
Part#:MAR-1P-3
Manufacturer:Clippard
Category:Pneumatic Components
Product Lifecycle:Active
Oct 13, 2026
Product description
Pressure Regulator, 1/8" NPT Inlet, #10-32 Outlet, Knurled Knob, 10-30 psig
Product Details
- Operating Temperature Range 32 to 230°F (0 to 110°C)
- Weight 0.1800
- Relieving Option Relieving (Standard)
- Adjustment Knurled Knob (Std.)
- Ports (Inlet / Outlet) Std. - 1/8" NPT /#10-32
- Air Flow 85 l/min @ 50 psig; 140 l/min @ 100 psig
- 2D Files 2D Files
- Travel Arc 7/32"
- Force 25 lb. Nominal
- Included Item(s) Nuts
- Operating Pressure 10 to 30 psig
- Input PSI 300 psig max.
- Mount #15/323-32 thread. Nuts and lockwashers furnished.
- Medium Air
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of MAR-1P-3 on Applied Automation is $30.65. Order now.
MAR-1P-3 Related Documents
Similar products from: Clippard Pneumatic Components
This item can ship in 3-5 days!
Manufacturer warranty
MAR-1P-3 Clippard
$30.65
Your price can be lower.
Log in or Create account to check your discount
Stock:
Select Qty:
$30.65
$30.65 each
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare MAR-1P-3 with other Pneumatic Components products
Operating Temperature Ran...
Weight
Relieving Option
Adjustment
Ports (Inlet / Outlet)
Air Flow
2D Files
Travel Arc
Force
Included Item(s)
Selected product
MAR-1P-3
Clippard
Pressure Regulator, 1/8" NPT Inlet, #10-32 Outlet, Knurled Knob, 10-30 psig
Operating Temperature Range32 to 230°F (0 to 110°C)
Weight0.1800
Relieving OptionRelieving (Standard)
AdjustmentKnurled Knob (Std.)
Ports (Inlet / Outlet)Std. - 1/8" NPT /#10-32
Air Flow85 l/min @ 50 psig; 140 l/mi...
2D Files2D Files
Travel Arc7/32"
Force25 lb. Nominal
Included Item(s)Nuts
DV-3M-24
Clippard
DV 3-Way Valve, Wire Leads, Manifold Mount, 24 VDC, Manifold Options: 15781-2, 15781-4, 15490-5
Operating Temperature Range32 to 130°F (0 to 55°C) at c...
Weight0.1500
Relieving Option-
Adjustment-
Ports (Inlet / Outlet)-
Air Flow-
2D Files2D Files
Travel Arc-
Force-
Included Item(s)-
Operating Temperature Range32 to 150°F (0 to 66°C)
Weight0.0850
Relieving Option-
Adjustment-
Ports (Inlet / Outlet)-
Air Flow-
2D Files-
Travel Arc-
Force-
Included Item(s)-
About the manufacturer
Clippard is a premier manufacturer of high-precision miniature pneumatic components and control systems. Renowned for their reliability and innovative design, Clippard products—including valves, cylinders, and electronic fluid controls—serve as the foundational components for advanced industrial automation, life sciences, and packaging applications worldwide.
About the Product Category
Components that are pneumatic are crucial elements of a pneumatic system, using compressed air to manage movements and carry out a range of tasks in industries like manufacturing, construction, and automation.
