05036ET3E326TS-W22G WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 230/460 V
- Output Rating 50 HP
- Rated Speed 3560 rpm
- Flange Type Without
- No load current 28.0/14.0 A
- Duty Cycle Cont.(S1)
- Approx. weight³ 543 lb
- L. R. Amperes 707/353 A
- Design B
- Noise level² 76.0 dB(A)
- Rated current 112/56.1 A
- Insulation Class F
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Output 50 HP (37 kW)
- Temperature rise 80 K
- LRC 6.3x(Code G)
- Standard NEMA MG-1
- Slip 1.11 %
- Locked rotor time 36s (cold) 20s (hot)
- Mounting F-1
- Rated speed 3560 rpm
- Rated torque 73.8 ft.lb
- Starting Method Direct On Line
- Voltage 230/460//380 V
- Number of Poles 2
- Breakdown torque 240 %
- Ambient temperature -20°C to +40°C
- Number of poles 2
- Frame 324/6TS
- Rated voltage 230/460 V
- Service factor 1.25
- Enclosure IC411 - TEFC
- Flange Without
- Frequency 60 Hz
- Moment of inertia (J) 5.75 sq.ft.lb
- Altitude 1000 m.a.s.l.
- Synchronous speed 3600 rpm
- Degree of Protection IP55
- Locked rotor torque 240 %
- Output rating 50 HP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
