E310A-1L012 Clippard Electronic Components

E310A-1L012 on Applied Automation
Clippard

Part#:E310A-1L012

Manufacturer:Clippard

Category:Electronic Components

Product Lifecycle:Active

Product description

10 mm N-C 3-way Valve, 90° Connector, 12 VDC

Product Details

  • Length
    1.08
  • Mount
    2 M17 screws
  • Connection
    90° with LED
  • Operating Temperature Range
    14 to 122°F (-10 to 50°C) When below 32°F, must use clean, dry air.
  • Max. Flow
    13 l/min @ 100 psig
  • Function
    3-Way Normally-Closed
  • Materials
    Stainless steel core and springs, nylon body, FKM dynamic seals, and Nitrile gasket and static seals. FKM gasket and static seals available.
  • Medium
    Air, Water, Gas or Compatible Fluids
  • Connector Wire
    Molex #28139 plug with terminal insert #50212-8000
  • Wattage
    0.6 Watts
  • Manifolds
    10 mm Manifolds
  • Voltage
    12 VDC
  • Coil Insulation Class
    F 311°F (155°C)
  • Voltage Operating Range
    ±10%
  • Accessories
    Connector with cable: C2A-RB300 (30 cm), C2A-RB500 (50 cm), C2A-RB1000 (1 m)
  • Weight
    0.0250
  • Operating Pressure
    0 to 100 psig (7 bar)
  • Response Time
    10 ms nominal

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of E310A-1L012 on Applied Automation is $28.55. Order now.
