E2L15E-4W024 Clippard Pneumatic Components
Part#:E2L15E-4W024
Manufacturer:Clippard
Category:Pneumatic Components
Product Lifecycle:Active
Oct 13, 2026
Product description
2-Way Latching Valve, Molded Wires, 1.1 mm Orifice, 24 VDC, A minimum order of 250 valves is required.
Product Details
- Coil Insulation Class F 311°F (155°C) / H356°F (180°C)
- Connection 24 AWG Wire Leads, 11.8"
- Function 2-Way Latching
- Voltage 24 VDC
- Length 1.08
- Response Time 10 ms nominal
- Wire Connector 3-Wire Molded Cord, 24 AWG, 300 mm length, 4.5 mm external jacket; tinned copper wires; silicone jacket and conductor insulation.
- Medium Air, Water, Gas or Compatible Fluids
- Materials Stainless steel core & springs, nylon body, FKM dynamic seals, and Nitrile gasket & static seals. FKM gasket & static seals available
- Voltage Tolerance ±10%
- Max. Flow 84 l/min @ 145 psig
- Wattage 4.0 Watts
- Operating Temperature Range 23 to 122°F (-5 to 50°C) When below 32°F, must use clean, dry air.
- Weight 0.0850
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of E2L15E-4W024 on Applied Automation is $68.52. Order now.
E2L15E-4W024 Related Documents
Similar products from: Clippard Pneumatic Components
This item can ship in 3-5 days!
Manufacturer warranty
E2L15E-4W024 Clippard
$68.52
Your price can be lower.
Log in or Create account to check your discount
Stock:
Select Qty:
$68.52
$68.52 each
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare E2L15E-4W024 with other Pneumatic Components products
Coil Insulation Class
Connection
Function
Voltage
Length
Response Time
Wire Connector
Medium
Materials
Voltage Tolerance
Selected product
E2L15E-4W024
Clippard
2-Way Latching Valve, Molded Wires, 1.1 mm Orifice, 24 VDC, A minimum order of 250 valves is require...
Coil Insulation ClassF 311°F (155°C) / H356°F (18...
Connection24 AWG Wire Leads, 11.8"
Function2-Way Latching
Voltage24 VDC
Length1.08
Response Time10 ms nominal
Wire Connector3-Wire Molded Cord, 24 AWG, ...
MediumAir, Water, Gas or Compatibl...
MaterialsStainless steel core & sprin...
Voltage Tolerance±10%
Coil Insulation Class-
ConnectionWire Leads, Side (Radial), 1...
Function3-Way Universally-Ported
Voltage24 VDC
Length.92
Response Time5 to 10 ms (nominal)
Wire Connector-
MediumClean, Dry Air and Compatibl...
Materials-
Voltage Tolerance-
DV-3M-24
Clippard
DV 3-Way Valve, Wire Leads, Manifold Mount, 24 VDC, Manifold Options: 15781-2, 15781-4, 15490-5
Coil Insulation Class-
ConnectionWire Leads, 18"
Function3-Way Fully-Ported, Universa...
Voltage24 VDC
Length-
Response Time10 to 15 milliseconds
Wire Connector-
MediumCompatible Fluids (40 micron...
Materials-
Voltage Tolerance-
About the manufacturer
Clippard is a premier manufacturer of high-precision miniature pneumatic components and control systems. Renowned for their reliability and innovative design, Clippard products—including valves, cylinders, and electronic fluid controls—serve as the foundational components for advanced industrial automation, life sciences, and packaging applications worldwide.
About the Product Category
Components that are pneumatic are crucial elements of a pneumatic system, using compressed air to manage movements and carry out a range of tasks in industries like manufacturing, construction, and automation.
Recently viewed products
Relevant products
FAQ
What is the price of E2L15E-4W024?
Purchase the E2L15E-4W024 from Applied Automation at the price of $68.52. Order today.
Out if stock but available for backorder.
2-Way Latching Valve, Molded Wires, 1.1 mm Orifice, 24 VDC, A minimum order of 250 valves is required.
