DR-2CNR Clippard Electronic Components

DR-2CNR on Applied Automation
Clippard

Part#:DR-2CNR

Manufacturer:Clippard

Category:Electronic Components

Product Lifecycle:Active

Product description

DR-2 Precision Regulator, Cartridge, Non-Relieving, 2-100 psig

Product Details

  • Medium
    Air, Water or Oil
  • Included Item(s)
    Nut & lockwashers
  • Input PSI
    300 psig max.
  • Unit
    Imperial
  • Non-Relieving Option
    Non-Relieving
  • Set Point Stability
    0.1 psig (0.007 bar)
  • Ports (Inlet - Outlet)
    Cartridge
  • Material
    Electroless nickel plated brass body, FKM seals, PFPE lube, stainless steel adjustment screw and spring
  • Mount
    #5/16-24 thread (M8x1.0 thread)
  • Set Point Sensitivity
    0.1 psig (0.007 bar)
  • Adjustment
    Screwdriver Slot
  • Weight
    0.3000
  • Accessories
    Knob & Set Screw: AK2.5-B
  • Operating Temperature Range
    32 to 230°F (0 to 110°C)
  • Max. Working Pressure
    2 to 100 psig (0.1-6.9 bar)
  • Repeatability
    ±0.1 psig typical (±0.15 psig max) (±0.007 bar)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DR-2CNR on Applied Automation is $60.79. Order now.
