570.100.68 Werma Buzzers

Product Details

• Materials
  PC/ABS
• Cable entry maximum
  d = 10 mm
• Operating voltage type
  AC
• Acoustic signal image
  Pulse tone
• Conform with ATEX-directive
  No
• Conforms with VdS
  No
• Cable entry
  Through hole
• Height
  360 mm
• Operating voltage
  230V
• Product weight
  920 g
• Rated inrush current
  <500mA
• Isolation voltage
  Ui = 250V; Uimp = 2.500V
• Volume (max) at 1m distance
  108,0 dB (A)
• Conforms with UL
  No
• ICAO Certification
  No
• Conforms with GL
  No
• cross-sectional area maximum
  2,50mm² / 14AWG
• Length
  152 mm
• Working temperature minimum
  -20°C
• Type of fixing
  Wall mounting
Operating voltage frequency
50Hz
Housing colour
Grey
Connection
Screw terminals
Weight with packaging
1070 g
Operating voltage tolerance
+/- 10%
Rated operational voltage
230 VAC
Overvoltage category
II
Conforms with CE
Yes
Conforms with IC
No
EAC certificate available
Yes
Protection category
IP55
Rated operational current
70 mA
Acoustic service life
250 h minimum
WEEE
Yes
Pollution degree
3
Conforms with FCC
No
Conforms with RoHS CN
No
Diameter
148 mm
Working temperature maximum
+60°C
Protection class
Protection class 2
Conforms with CCC
No
Conforms with AS-I
No
