12536OT3G404TSC-RFW4 WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  460 V
• Output Rating
  125 HP
• Rated Speed
  3557 rpm
• Flange Type
  C
• LRC
  6.8x(Code G)
• Enclosure
  IC01 - ODP
• Synchronous speed
  3600 rpm
• Rated speed
  3557 rpm
• No load current
  36.0 A
• Starting Method
  Direct On Line
• Output rating
  125 HP
• L. R. Amperes
  925 A
• Rated torque
  185 ft.lb
• Ambient temperature
  -20°C to +40°C
• Noise level²
  84.0 dB(A)
• Slip
  1.19 %
• Design
  B
• Altitude
  1000 m.a.s.l.
• Voltage
  460 V
Frequency
60 Hz
Insulation Class
F
Approx. weight³
886 lb
Number of poles
2
Rated voltage
460 V
Moment of inertia (J)
8.23 sq.ft.lb
Degree of Protection
IP23
Terminal box¹
Left position
Rated current
136 A
Service factor
1.25
Standard
NEMA MG-1
Output
125 HP
Locked rotor torque
170 %
Mounting
F-1
Flange
C
Frame
404/5TSC
Breakdown torque
260 %
Temperature rise
80 K
Rotation¹
Both (CW and CCW)
Number of Poles
2
Locked rotor time
21s (cold) 12s (hot)
Duty Cycle
Cont.(S1)
