10671885 WEG AC Motors

Product Details

• Number of Poles
  2
• Locked rotor torque
  250 %
• Enclosure
  IC418 - TEAO
• Approx. weight³
  98.8 lb
• Frame
  184Y
• Breakdown torque
  400 %
• Starting Method
  Direct On Line
• Synchronous speed
  3600 rpm
• Output
  3 HP (2.2 kW)
• Insulation Class
  F
• Rotation¹
  Both (CW and CCW)
• Flange
  Without
• Rated speed
  3510 rpm
• Rated torque
  4.49 ft.lb
• Altitude
  1000 m.a.s.l.
• Rated current
  8.13-7.35/3.67 A
• Locked rotor time
  77s (cold) 43s (hot)
• Duty Cycle
  Cont.(S1)
• Standard
  NEMA MG-1
• LRC
  8.8x(Code K)
Ambient temperature
40°C to +40°C
Voltage
208-230/460 V
Frequency
60 Hz
Design
B
Mounting
F-1
Output rating
3 HP
Rated voltage
208-230/460 V
Moment of inertia (J)
0.1998 sq.ft.lb
Temperature rise
80 K
Terminal box¹
Left position
Slip
2.50 %
No load current
2.65-3.08/1.54 A
Degree of Protection
IP55
Noise level²
69.0 dB(A)
Material (FERT)
50006910
L. R. Amperes
71.5-64.7/32.3 A
Service factor
1.25
Number of poles
2
