10018OT3E404TSC-W40 WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  230/460 V
• Output Rating
  100 HP
• Rated Speed
  1780 rpm
• Flange Type
  C
• Number of Poles
  4
• Rated torque
  295 ft.lb
• Temperature rise
  80 K
• Standard
  NEMA MG-1
• Rated speed
  1780 rpm
• Design
  B
• Service factor
  1.25
• Synchronous speed
  1800 rpm
• Frame
  404/5TSC
• Altitude
  1000 m.a.s.l.
• Noise level²
  69.0 dB(A)
• Output
  100 HP (75 kW)
• Insulation Class
  F
• Mounting
  F-1
• Terminal box¹
  Left position
Frequency
60 Hz
No load current
74.0/37.0 A
Degree of Protection
IP23
Voltage
230/460//380 V
Rated current
229/115 A
Moment of inertia (J)
21.9 sq.ft.lb
Enclosure
IC01 - ODP
Number of poles
4
Slip
1.11 %
Breakdown torque
250 %
Starting Method
Direct On Line
Approx. weight³
998 lb
Rated voltage
230/460 V
L. R. Amperes
1560/780 A
Locked rotor torque
200 %
Locked rotor time
21s (cold) 12s (hot)
Duty Cycle
Cont.(S1)
Rotation¹
Both (CW and CCW)
Flange
C
LRC
6.8x(Code G)
Ambient temperature
-20°C to +40°C
Output rating
100 HP
