02589EP3HCT286VF1-W2 WEG AC Motors

Product Details

• Number of Poles
  45508 Pole
• Voltage
  575 V
• Output Rating
  6.25/25 HP
• Rated Speed
  1780 rpm
• Flange Type
  Without
• Rated current
  24.1 A
• Rated torque
  73.8 ft.lb
• Altitude
  1000 m.a.s.l.
• Voltage
  575 V
• Slip
  1.11 %
• Breakdown torque
  310 %
• Mounting
  F-1
• Synchronous speed
  900/1800 rpm
• Frequency
  60 Hz
• Insulation Class
  F
• Output rating
  6.25/25 HP
• Number of Poles
  8/4
• L. R. Amperes
  205 A
• Moment of inertia (J)
  5.85 sq.ft.lb
• Service factor
  1.25
Ambient temperature
-20°C to +40°C
Standard
NEMA MG-1
Flange
Without
LRC
8.5x(Code K)
Temperature rise
80 K
Frame
284/6T
Approx. weight³
468 lb
Output
25 HP (18.5 kW)
Starting Method
Direct On Line
Rated speed
1780 rpm
Enclosure
IC411 - TEFC
Terminal box¹
Left position
No load current
10.2 A
Degree of Protection
IP55
Number of poles
8/4
Rated voltage
575 V
Locked rotor torque
300 %
Rotation¹
Both (CW and CCW)
Locked rotor time
16s (cold) 9s (hot)
Duty Cycle
Cont.(S1)
Noise level²
64.0 dB(A)
