02536OT3H256T-W40 WEG AC Motors

Product Details

• Number of Poles
  2 Pole
• Voltage
  575 V
• Output Rating
  25 HP
• Rated Speed
  3535 rpm
• Flange Type
  Without
• Rated current
  23.0 A
• Design
  B
• Synchronous speed
  3600 rpm
• Slip
  1.81 %
• Insulation Class
  F
• Mounting
  F-1
• Approx. weight³
  220 lb
• LRC
  6.5x(Code G)
• Service factor
  1.25
• Output rating
  25 HP
• Number of Poles
  2
• Locked rotor time
  19s (cold) 11s (hot)
• Altitude
  1000 m.a.s.l.
• Voltage
  575 V
• Frame
  254/6T
Rated torque
37.1 ft.lb
Ambient temperature
-20°C to +40°C
Standard
NEMA MG-1
L. R. Amperes
150 A
Locked rotor torque
200 %
Degree of Protection
IP23
Flange
Without
Rated speed
3535 rpm
No load current
6.80 A
Temperature rise
80 K
Rotation¹
Both (CW and CCW)
Rated voltage
575 V
Moment of inertia (J)
1.13 sq.ft.lb
Enclosure
IC01 - ODP
Output
25 HP (18.5 kW)
Breakdown torque
280 %
Starting Method
Direct On Line
Terminal box¹
Left position
Frequency
60 Hz
Duty Cycle
Cont.(S1)
Number of poles
2
