00536ET3E184JM-SG WEG AC Motors

00536ET3E184JM-SG on Applied Automation
WEG

Part#:00536ET3E184JM-SG

Alt. Part#:7909265668990

Manufacturer:WEG

Category:AC Motors

Product Lifecycle:Active

Product description

Rolled Steel JM Pump NEMA Premium Efficiency 5 HP 2P 182/4JM 3Ph 230/460//190-220/380-415 V 60 Hz IC411 - TEFC - Foot-mounted

Product Details

  • Number of Poles
    2 Pole
  • Voltage
    230/460 V
  • Output Rating
    5 HP
  • Rated Speed
    3500 rpm
  • Flange Type
    C
  • Slip
    2.78 %
  • Breakdown torque
    300 %
  • Terminal box¹
    Left position
  • Rated current
    11.8/5.90 A
  • Rated torque
    7.50 ft.lb
  • Ambient temperature
    -20°C to +40°C
  • Number of poles
    2
  • Frequency
    60 Hz
  • Locked rotor time
    34s (cold) 19s (hot)
  • Enclosure
    IC411 - TEFC
  • Synchronous speed
    3600 rpm
  • Frame
    182/4JM
  • Starting Method
    Direct On Line
  • Insulation Class
    F
  • Output rating
    5 HP
  • L. R. Amperes
    92.0/46.0 A
  • LRC
    7.8x(Code J)
  • Locked rotor torque
    220 %
  • No load current
    4.40/2.20 A
  • Moment of inertia (J)
    0.2079 sq.ft.lb
  • Mounting
    F-1
  • Noise level²
    68.0 dB(A)
  • Voltage
    230/460//190-220/380-415 V
  • Number of Poles
    2
  • Duty Cycle
    Cont.(S1)
  • Standard
    NEMA MG-1
  • Output
    5 HP (3.7 kW)
  • Degree of Protection
    IP55
  • Rated voltage
    230/460 V
  • Design
    B
  • Altitude
    1000 m.a.s.l.
  • Approx. weight³
    89.3 lb
  • Rated speed
    3500 rpm
  • Temperature rise
    80 K
  • Rotation¹
    Both (CW and CCW)
  • Flange
    C

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
