00518ET3E184TC-SG WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 5 HP
- Rated Speed 1750 rpm
- Flange Type C
- Slip 2.78 %
- Output 5 HP (3.7 kW)
- No load current 6.89/3.44 A
- Duty Cycle Cont.(S1)
- Voltage 230/460//190-220/380-415 V
- Rated speed 1750 rpm
- Rated current 13.0/6.49 A
- Design B
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Frame 182/4TC
- Breakdown torque 300 %
- Degree of Protection IP55
- Standard NEMA MG-1
- Number of Poles 4
- Service factor 1.15
- Number of poles 4
- Insulation Class F
- Noise level² 56.0 dB(A)
- Locked rotor time 28s (cold) 16s (hot)
- Flange C
- Rated torque 15.0 ft.lb
- Enclosure IC411 - TEFC
- Rated voltage 230/460 V
- Temperature rise 80 K
- Output rating 5 HP
- Moment of inertia (J) 0.3080 sq.ft.lb
- LRC 7.0x(Code J)
- Altitude 1000 m.a.s.l.
- Approx. weight³ 83.8 lb
- Ambient temperature -20°C to +40°C
- Synchronous speed 1800 rpm
- Locked rotor torque 220 %
- L. R. Amperes 90.9/45.4 A
- Starting Method Direct On Line
- Frequency 60 Hz
- Mounting F-1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
