00312ST3QIE213TC-W22 WEG AC Motors
Product Details
- Number of Poles 6 Pole
- Voltage 460 V
- Output Rating 3 HP
- Rated Speed 1175 rpm
- Flange Type C
- Slip 2.08 %
- Moment of inertia (J) 1.20 sq.ft.lb
- Number of Poles 6
- Insulation Class F
- Starting Method Direct On Line
- Number of poles 6
- LRC 7.0x(Code K)
- Locked rotor time 104s (cold) 58s (hot)
- Enclosure IC411 - TEFC
- Flange C
- Rated speed 1175 rpm
- Service factor 1.25
- Rotation¹ Both (CW and CCW)
- Output 3 HP (2.2 kW)
- Design B
- Approx. weight³ 174 lb
- Terminal box¹ Left position
- L. R. Amperes 30.9 A
- Temperature rise 80 K
- Degree of Protection IP56
- Noise level² 55.0 dB(A)
- Frequency 60 Hz
- Breakdown torque 280 %
- Duty Cycle Cont.(S1)
- Output rating 3 HP
- Frame 213/5TC
- No load current 2.75 A
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
- Rated voltage 460 V
- Rated torque 13.4 ft.lb
- Voltage 460 V
- Rated current 4.41 A
- Locked rotor torque 200 %
- Altitude 1000 m.a.s.l.
- Synchronous speed 1200 rpm
- Mounting F-1
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
