.5018ES3E56CFL-S WEG AC Motors

Product Details

• Number of Poles
  4 Pole
• Voltage
  208-230/460 V
• Output Rating
  0.5 HP
• Rated Speed
  1760 rpm
• Flange Type
  C
• Output
  0.5 HP (0.37 kW)
• Service factor
  1.15 (1.00 @ 208V)
• Duty Cycle
  Cont.(S1)
• Output rating
  0.5 HP
• Frame
  56C
• LRC
  7.0x(Code L)
• Slip
  2.22 %
• Rated torque
  1.49 ft.lb
• Rotation¹
  Both (CW and CCW)
• Terminal box¹
  Left position
• No load current
  1.03-1.20/0.600 A
• Temperature rise
  80 K
• Degree of Protection
  IP55
• Flange
  C
• Rated voltage
  208-230/460 V
Locked rotor time
36s (cold) 20s (hot)
Ambient temperature
-20°C to +40°C
Number of poles
4
Rated speed
1760 rpm
Moment of inertia (J)
0.0584 sq.ft.lb
Mounting
F-1
Standard
NEMA MG-1
Frequency
60 Hz
Breakdown torque
300 %
Altitude
1000 m.a.s.l.
Rated current
1.91-1.72/0.862 A
Insulation Class
F
Noise level²
52.0 dB(A)
Voltage
208-230/460//190-220/380-415 V
Number of Poles
4
Locked rotor torque
240 %
Enclosure
IC411 - TEFC
Synchronous speed
1800 rpm
L. R. Amperes
13.3-12.1/6.03 A
Starting Method
Direct On Line
Approx. weight³
21.2 lb
