ZS 335-02Z-M20 Schmersal Electronic Components
Part#:ZS 335-02Z-M20
Alt. Part#:101169933
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Position switch; 335; Snap action with constant contact pressure up to switching point; 1 Cable entry M 20 x 1.5; Metal enclosure; Wide range of alternative actuators; Good resistance to oil and petroleum spirit; 40,5 mm x 76 mm x 38 mm; Actuator heads ca
Product Details
- Enclosure coating material painted
- Enclosure material Light alloy die-casting
- Actuator type to DIN EN 50041 B
- Gross weight 185 g
- Material of the contacts, electrical Silver
- Number of safety contacts 2
- Safety functions Yes
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Rated impulse withstand voltage Uimp 6 kV
- Actuating element Plunger
- Cable section, maximum 2.5 mm²
- Thermal test current 10 A
- Switching element Opener (NC)
- Housing construction form Norm construction design
- Length of sensor 38 mm
- Required rated short-circuit current to EN 60947-5-1 1,000 A
- Switchover time, maximum 2 ms
- Mechanical life, minimum 30,000,000 Operations
- Degree of protection IP65 to EN 60529, IP67 to EN 60529
- Rated insulation voltage Ui 500 V
- Switching principle Snap switch element
- Actuating speed, maximum 0.5 m/s
- Ambient temperature, minimum -30 °C
- Terminal Connector Screw connection
- Height of sensor 103.5 mm
- Utilisation category DC-13 24 VDC
- Actuating force, minimum 12 N
- Note Bounce duration Bounce duration in accordance with actuating speed
- Cable section, minimum 0.75 mm²
- Ambient temperature, maximum +80 °C
- Width of sensor 40.5 mm
- Utilisation category AC-15 4 A
- Switching frequency 5,000 /h
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of ZS 335-02Z-M20 on Applied Automation is $126.00. Order now.
