V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4 Schmersal Cable Assemblies
Part#:V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4
Alt. Part#:103003649
Manufacturer:Schmersal
Category:Cable Assemblies
Product Lifecycle:Active
Product description
V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4 Schmersal - Schmersal - V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4
Product Details
- Length of cable 2 m
- Connector typ Male connector, M12
- Temperature (fixed), minimum -50 °C
- Wire cross-section 0.3 mm2
- Connector latching Screw locking
- Material of the gland Metal, CuZn, nickel-plated
- Temperature (repeated), minimum -25 °C
- Halogen free Yes (1)
- Material of the Cable mantle PUR
- Temperature (fixed), maximum +90 °C
- Thermal test current 4 A
- Cable drag chain suitable Yes (1)
- Standards IEC 61076-2-101
- Connector coding A
- Degree of protection IP67
- Operating current 4,000 mA
- Cable diameter 6 mm
- Tightening torque, maximum 1 Nm
- Material of the handle Plastic, TPU
- Temperature (repeated), maximum +90 °C
- Number of poles 4
- Bending radius (repeated) 10 x Ø-cable
- Design straight
- Ambient temperature, maximum (Connector) +85 °C
- Gross weight 80 g
- Colour of the Cable mantle Black
- Number of cable wires 4
- Bending radius (fixed) 5 x Ø-cable
- Colour of the handle Black
- Ambient temperature, minimum (Connector) -25 °C
- Rated operating voltage 30 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4 on Applied Automation is $48.00. Order now.
V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4 Related Documents
Manufacturer warranty
V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4 Schmersal
$48.00
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$48.00
$48.00 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Compare V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4 with other Cable Assemblies products
Length of cable
Connector typ
Temperature (fixed), mini...
Wire cross-section
Connector latching
Material of the gland
Temperature (repeated), m...
Halogen free
Material of the Cable man...
Temperature (fixed), maxi...
Selected product
V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4
Schmersal
V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4 Schmersal - Schmersal - V-SK4P-M12/M8-S-G-2M-BK-2-X-A-4
Length of cable2 m
Connector typMale connector, M12
Temperature (fixed), minimum-50 °C
Wire cross-section0.3 mm2
Connector latchingScrew locking
Material of the glandMetal, CuZn, nickel-plated
Temperature (repeated), minimum-25 °C
Halogen freeYes (1)
Material of the Cable mantlePUR
Temperature (fixed), maximum+90 °C
Length of cable-
Connector typ-
Temperature (fixed), minimum-
Wire cross-section-
Connector latching-
Material of the gland-
Temperature (repeated), minimum-
Halogen free-
Material of the Cable mantle-
Temperature (fixed), maximum-
About the manufacturer
Applied Automation is an authorized Schmersal distributor, proudly offering a diverse range of innovative safety and automation solutions tailored to meet the rigorous demands of modern industries. Schmersal is a globally renowned manufacturer specializing in the development and production of high-quality safety systems designed to protect both personnel and machinery across various industrial sec...
