TS256-02ZH Schmersal Electronic Components
Part#:TS256-02ZH
Alt. Part#:101145285
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Position switches (Archive); 256 thermoplastic enclosure - EN 50047 with actuator; 2 cable entries M 20 x 1.5; Mounting details to EN 50047; Thermoplastic enclosure; Double-insulated; 58 mm x 50,5 mm x 31 mm; Good resistance to oil and petroleum spirit; W
Product Details
- Ambient temperature, minimum -30 °C
- Utilisation category DC-13 24 VDC
- Number of safety contacts 2
- Actuating force, minimum 9 N
- Width of sensor 58 mm
- Housing construction form Norm construction design
- Cable section, maximum 2.5 mm²
- Ambient temperature, maximum +80 °C
- Actuating element Plunger
- Note Bounce duration Bounce duration in accordance with actuating speed
- Height of sensor 62.5 mm
- Switching element Opener (NC)
- Standards BG-GS-ET-15, EN ISO 13849-1, IEC 60947-5-1
- Actuating speed, minimum 60 mm/min
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Thermal test current 10 A
- Switching principle Slow action with staggered contacts
- Actuator type to DIN EN 50047 B
- Terminal Connector Screw connection
- Enclosure material Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
- Positive break force, minimum 19 N
- Cable section, minimum 0.75 mm²
- Utilisation category AC-15 4 A
- Switching frequency 5,000 /h
- Material of the contacts, electrical Silver
- Actuating speed, maximum 1 m/s
- Rated impulse withstand voltage Uimp 6 kV
- Required rated short-circuit current to EN 60947-5-1 1,000 A
- Mechanical life, minimum 20,000,000 Operations
- Safety functions Yes
- Note (Switchover time) Switchover time in accordance with actuating speed
- Length of sensor 31 mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
