TQ 200-01 Schmersal Electronic Components

Product Details

• Terminal Connector
  Shielded cable
• Length of cable
  3 m
• Degree of protection of the control element
  IP67
• Restistance to shock
  30 g
• Required rated short-circuit current to EN 60947-5-1
  1,000 A
• Actuating speed
  60 mm/min
• Height
  250 mm
• Storage and transport temperature, maximum
  +80 °C
• Overvoltage category
  III
• Enclosure material
  Light alloy die-casting
• Wire cross-section
  1 mm2
• Ambient temperature, maximum
  +80 °C
• Protection rating
  II
• Number of openers
  1
• Gross weight
  706 g
• Storage and transport temperature, minimum
  -40 °C
• Standards
  EN 60947-5-1
• Width
  60 mm
• Relative humidity, maximum
  93 %
• Degree of pollution to VDE 0100
  3
Actuating force, maximum
44 N
Degree of protection
IP54
Resistance to vibrations to EN 60068-2-6
10 - 150 Hz (0.5 mm / 5 g)
Thermal test current
1 A
Mechanical life, minimum
1,000,000 Operations
Depth
32 mm
Rated insulation voltage Ui
40 V
Actuating force, minimum
36.8 N
Ambient temperature, minimum
-40 °C
Rated impulse withstand voltage Uimp
2.5 kV
Switching element
Opener (NC)
Note (Relative humidity)
non-condensing
Switching principle
Creep circuit element
