TESK-SA-11L1-3M Schmersal Safety Switches
Part#:TESK-SA-11L1-3M
Alt. Part#:103005740
Manufacturer:Schmersal
Category:Safety Switches
Product Lifecycle:Active
Product description
TESK-SA-11L1-3M Schmersal - Safety switch for hinged guards; Hinge safety switch; cable bottom; with fixed switching angle; pre-set for front mounting; Standard hinge; Metal enclosure
Product Details
- Colour of the housing Silver
- Material of the contacts, electrical Silver-nickel alloy 10
- Rated insulation voltage Ui 300 V
- Switching element NO contact, NC contact
- Terminal Connector cable
- Width of sensor 78 mm
- Degree of protection IP65
- Utilisation category DC-13 1 A
- Alignment aid Yes
- Cable section, maximum 1 mm²
- Ambient temperature, maximum +65 °C
- Number of safety contacts 1
- Length of cable 3 m
- Thermal test current 2.5 A
- Switching frequency 1,200 /h
- Mounting outside Yes
- Cable section, minimum 0.5 mm²
- Utilisation category AC-15 2 A
- Switching principle Creep circuit element
- Mechanical life, minimum 1,000,000 Operations
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Enclosure material Zinc die-cast
- Height of sensor 116 mm
- Rated impulse withstand voltage Uimp 2.5 kV
- Number of auxiliary contacts 1
- Ambient temperature, minimum -25 °C
- Length of sensor 20 mm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TESK-SA-11L1-3M on Applied Automation is $301.00. Order now.
TESK-SA-11L1-3M Related Documents
Similar products from: Schmersal Safety Switches
Manufacturer warranty
TESK-SA-11L1-3M Schmersal
$301.00
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$301.00
$301.00 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
