T4VH 335-11Z-M20 Schmersal Electronic Components

Product Details

• Housing construction form
  Norm construction design
• Mechanical life, minimum
  30,000,000 Operations
• Length of sensor
  60.6 mm
• Thermal test current
  10 A
• Switching frequency
  5,000 /h
• Roller material
  Plastic
• Note (Switchover time)
  Switchover time in accordance with actuating speed
• Enclosure coating material
  painted
• Enclosure material
  Light alloy die-casting
• Number of auxiliary contacts
  1
• Note (Actuating speed)
  Actuating speed with actuating angle 30° to switch axis
• Actuating torque, minimum
  0.3 Nm
• Width of sensor
  40.5 mm
• Degree of protection
  IP65 to EN 60529, IP67 to EN 60529
• Utilisation category AC-15
  4 A
• Gross weight
  265 g
• Number of safety contacts
  1
• Cable section, maximum
  2.5 mm²
• Rated impulse withstand voltage Uimp
  6 kV
• Lever material
  Metal film
Actuating element
Roller lever
Cable section, minimum
0.75 mm²
Ambient temperature, maximum
+80 °C
Bounce duration, maximum
2 ms
Material of the contacts, electrical
Silver
Actuating speed, maximum
2.5 m/s
Note (Cable section)
All indications about the cable section are including the conductor ferrules.
Rated insulation voltage Ui
500 V
Switching element
NO contact, NC contact
Actuator type to DIN EN 50041
A
Safety functions
Yes
Terminal Connector
Screw connection
Ambient temperature, minimum
-30 °C
Utilisation category DC-13
24 VDC
Height of sensor
134 mm
Required rated short-circuit current to EN 60947-5-1
1,000 A
Switching principle
Slow action
