T. 441-11Y-M20-243 Schmersal Electronic Components
Part#:T. 441-11Y-M20-243
Alt. Part#:101170427
Manufacturer:Schmersal
Category:Electronic Components
Product Lifecycle:Active
Product description
Belt alignment switch; 2 cable entries M20; Metal enclosure; 2 Contacts; 106 mm x 99 mm x 63 mm ( basic component); Suitable for heavy duty
Product Details
- Number of openers 1
- Cable section, minimum 1.5 mm²
- Rated insulation voltage Ui 400 V
- Switching frequency 3,000 /h
- Active principle mechanical
- Length of sensor 63 mm
- Ambient temperature, maximum +90 °C
- Switching element NO contact, NC contact
- Gross weight 1,821.8 g
- Cable section, maximum 2.5 mm²
- Width of the lever 25 mm
- Contact opening 2 x 6 mm
- Enclosure material Grey cast iron, galvanised
- Degree of protection IP65 to EN 60529
- Utilisation category AC-15 4 A
- Number of shutters 1
- Actuation direction each time 60° right-hand side and left-hand side rotation
- Width of sensor 106 mm
- Mechanical life, minimum 10,000,000 Operations
- Enclosure coating material painted
- Length of the lever 25 mm
- Ambient temperature, minimum -30 °C
- Terminal Connector Screw connection
- Material of the contacts, electrical Silver
- Height of the lever 141 mm
- Thermal test current 16 A
- Standards EN 60947-5-1
- Height of sensor 99 mm
- Diameter of Castor 25 mm
- Switching principle Creep circuit element
- Rated impulse withstand voltage Uimp 6 kV
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
