RDRZ45GN Schmersal Pushbuttons

Product Details

• Material of the operators
  Aluminium powder-coated
• Mechanical life, minimum
  100,000 Operations
• Diameter hole, with tolerance indication
  22.3 + 0.4 mm
• Standards
  EN ISO 13850, IEC/EN 60947-5-5
• Snap-action mechanism integrated
  Yes
• Fully insulated
  Yes
• Thickness, of the front panel, minimum
  1 mm
• Ambient temperature, maximum
  +75 °C
• Versions
  Latched pushbutton - Front plate mounting
• Material of the front ring
  Aluminium
• Actuating stroke
  4 mm
• Diameter hole
  22.3 mm
• Restistance to shock
  50 g
• Sealing type
  Membrane, Lip gaskets, Form seals
• Colour of the operating element
  Green
• Mounting
  Mounting flange EFM
• Spacing
  50 x 60 mm
• Installation conditions (mechanical)
  arbitrarily
• Unlocking
  Draw unlocking
• Diameter total
  45 mm
Ambient temperature, minimum
-25 °C
Colour of the front ring
Silver
Mounting flange
Yes
diameters for the actuating heads
45 mm
Design
Round
Latching
Yes
Height
27.5 mm
Degree of protection
IP65
Gross weight
70 g
Tightening torque of the screw
0.6 Nm
Thickness of the front panel, maximum
6 mm
