NDLWS Schmersal Indicator Lights

Product Details

• Colour of the operating element
  White
• Tightening torque of the screw
  0.6 Nm
• Diameter of the front ring
  44.5 mm
• Colour of the front ring
  Silver
• Actuating stroke
  5 mm
• Height
  28 mm
• Ambient temperature, maximum
  +80 °C
• Material of the operators
  ABS
• Probing possible
  Yes
• Diameter of touch surface
  27 mm
• Degree of protection
  IP67, IP69K
• Standards
  EN 60947-5-1, IEC/EN 60947-1
• Versions
  Embeddable button - Front plate mounting
• Illuminable
  Yes
• Thickness of the front panel, maximum
  6 mm
• Design
  Round
• Gross weight
  30 g
• Fully insulated
  Yes
• Thickness, of the front panel, minimum
  1.5 mm
• Sealing type
  Membrane, Lip gaskets
Mounting flange
Yes
Diameter total
44.5 mm
Colour of the bellows
White
Mounting
Mounting flange ELM
Spacing
50 x 50 mm
Material of the front ring
ABS, chrome-plated
Diameter hole
22.3 mm
Ambient temperature, minimum
-25 °C
Unlocking
without
Diameter hole, with tolerance indication
22.3 + 0.4 mm
