ML30.241-70 Schmersal AC/DC Power Supplies

Product Details

• Number of LEDs
  1
• Cable section, minimum
  0.5 mm²
• Ambient temperature, minimum
  -10 °C
• Ambient temperature, maximum
  +70 °C
• Rated operating voltage
  100 VAC - 240 VAC, −15 % / +10 %
• EMC rating
  EMC-Directive
• Standards
  EN 60204-1, EN 50178, IEC 62103
• Mounting
  Snaps onto standard DIN rails to IEC 60715
• Height
  75 mm
• Storage and transport temperature, maximum
  +85 °C
• Degree of pollution to IEC/EN 60664-1
  2
• Rated AC voltage for controls, 60 Hz, minimum
  100 VAC
• Rated control voltage at DC, maximum
  300 VDC
• Gross weight
  140 g
• Cable section, maximum
  6 mm²
• Storage and transport temperature, minimum
  -40 °C
• Operating current
  0.3 mA, 0.54 mA
• Rated AC voltage for controls at DC minimum
  110 VDC
• Integral System Diagnostics, status
  Yes
• Width
  22.5 mm
Degree of protection of the enclosure
IP20
Rated AC voltage for controls, 50 Hz, minimum
100 VAC
Climatic stress
IEC 60068-2-30
Tightening torque of Clips
1 Nm
Restistance to shock
30 g 6 ms, 20 g 11 ms (IEC 60068-2-27)
Frequency range
50 Hz, 60 Hz
Rated control voltage at AC 60 Hz, maximum
240 VAC
Terminal Connector
Screw connection, rigid or flexible
Depth
91 mm
Resistance to vibrations to EN 60068-2-6
2
Rated control voltage at AC 50 Hz, maximum
240 VAC
