EF033F.3 Schmersal Electronic Components

Product Details

• positive break travel
  2 mm
• Contact labelling
  53-54, 63-64
• Mounting flange position
  3
• Switching frequency
  1,200 /h
• Installation instructions
  pluggable
• Terminal Connector
  Flat plug-in connector - 6.3 mm x 0.8 mm / 2 x 2.8 mm x 0.8 mm
• Ambient temperature, minimum
  -25 °C
• Switching principle
  Slow action
• Gross weight
  20 g
• Contact opening
  3 mm
• Ambient temperature, maximum
  +80 °C
• Suitable for low-voltages
  ≥ 5 V / ≥ 3.2 mA
• Standards
  EN 60947-5-1, IEC/EN 60947-1
• Enclosure material
  Plastic, glass-fibre reinforced thermoplastic, self-extinguishing
• Degree of protection of the switch rooms
  IP40
• Rated insulation voltage Ui
  400 V
• Suitable for EMERGENCY-OFF
  Yes
• Length
  46 mm
• Utilisation category AC-15
  8 A
• Bounce duration, maximum
  5 ms
Material of the contacts, electrical
Silver
Width
10 mm
Thermal test current
10 A
Switching element
Normally open contact (NO)
Mechanical life, minimum
10,000,000 Operations
Note Bounce duration
Bounce duration at an Actuating speed of 100mm/s
Restistance to shock
110 g / 4 ms
Degree of protection of clips or terminals
IP20
Utilisation category DC-13
24 VDC
Number of shutters
2
Depth
60 mm
Resistant to vibration
Resistance to vibration: 20 g / 10…200 Hz
