BWU3635 Schmersal Safety Accessories

Product Details

• Standards
  EN 62061, EN 62026-2, EN ISO 13849-1
• Degree of protection
  IP67
• Ambient temperature, minimum
  -20 °C
• Storage and transport temperature, maximum
  +85 °C
• Restistance to shock
  15 g / 11 ms
• AS-i Operating voltage AS-i maximum
  31.6 VDC
• AS-i Current consumption, maximum
  60 mA
• Safety functions
  Yes
• AS-i Version
  V 2.1
• Height
  45 mm
• Depth
  19 mm
• Ambient temperature, maximum
  +60 °C
• Width
  60 mm
• Storage and transport temperature, minimum
  -30 °C
• Resistance to vibrations to EN 60068-2-6
  10 … 55 Hz, amplitude 0.5 mm
• AS-i Operating voltage, minimum
  21.6 VDC
• AS-i Specification
  Safety-Slave
• Terminal Connector
  Cable connector M12, 8-pole, A-coded
• Material of the cable
  PUR
• AS-i Input, Channel 1
  Data bits DI 0 / DI 1 = dynamic code transmission
AS-i Outputs, DO 1 … DO 3
No Function
AS-i Input module address
0
Enclosure material
Plastic
AS-i Outputs, DO 0
Digital output, Solenoid control
AS-i Parameter bits, P1
Diagnostics signal safety switchgear (inverted)
Note (AS-i Input module address)
Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
AS-i Profile
S-7.B.F.1
AS-i Input, Channel 2
Data bits DI 2 / DI 3 = dynamic code transmission
AS-i Parameter bits, P2 ... P3
No function
Rated operating voltage
24 VDC -15% / +10% (stabilised PELV)
Reaction time, maximum
11 ms
Note (AS-i Parameter bits)
Set the parameter outputs to "1111" (0xF)
Integral System Diagnostics, status
Yes
AS-i Parameter bits, P0
Control system watchdog
Length of cable
1 m
Gross weight
141.3 g
