BN 31-RZ Schmersal Electronic Components

Product Details

• Enclosure material
  Glass-fibre, reinforced thermoplastic
• Restistance to shock
  30 g / 11 ms
• Active principle
  Magnetic drive
• Mounting
  Enclosure with mounting slots
• Height of sensor
  25 mm
• Actuating element
  Magnet
• Suitable for elevators
  Yes
• Notice (Switch distance Sn)
  Actuating distance up to 60 mm depending on actuating magnet and version. The specified switching distances are applicable for the actuation of individually mounted components without ferromagnetic influence. A change of the distance, either positive or n
• Degree of protection
  IP67 to EN 60529
• Repeat accuracy R R
  0.3 mm
• Housing construction form
  rectangular
• Material of the Cable mantle
  H03VV-F
• Resistance to vibrations to EN 60068-2-6
  10 … 55 Hz, amplitude 1 mm
• Actuating speed, maximum
  18 m/s
• Active area
  Plastic
• Length of sensor
  13 mm
• Versions
  Reed contacts
• Mechanical life, minimum
  1,000,000,000 Operations
• Gross weight
  70 g
• Width of sensor
  88 mm
Switching current, maximum
3 A
Ambient temperature, minimum
-25 °C
Wire cross-section
18 AWG
Number of snap-in contacts
1
Switching capacity, maximum
80 VA
Length of cable
1 m
Latching
Yes
Ambient temperature, maximum
+75 °C
