W1413A1408W ROSS Controls Electronic Components
Part#:W1413A1408W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
Miniature Valve, W14 Series, 3/2 Single, Solenoid Controlled, Poppet, Locking Manual Override, 24 VDC
Product Details
- Valve Body Material Cast Aluminum
- Width 2.40 in (61 mm)
- Seal Material Buna-N
- Width (mm) 61
- Weight (kg) 0.45 kg
- Weight 1.0 lb (0.45 kg)
- Height (mm) 64
- Height 2.5 in (64 mm)
- Fluid Media Filtered air
- Media Temperature 5 to 175 F (-15 to 80 C)
- Length (mm) 30
- Operating Pressure Vacuum to 150 psig (10 bar)
- Length 1.2 in (30 mm)
- Operating Pressure (bar) Vacuum to 10
- Ambient Temperature 5 to 120 F (-15 to 50 C)
- Media Temperature (Celsius) -15 to 80
- Ambient Temperature (Celsius) -15 to 50
- Power Consumption 6 watts
- Duty Rating Continuous Duty
- Voltage 24 VDC
- Manual Override Locking
- Cv (1-2) 0.1
- Connection EN 175301-803 Form A
- Actuation Electrical
- Return Spring
- Default Position Normally Closed
- Application Standard
- Series W14
- Construction Poppet
- Function 3/2 Single Direct Solenoid
- Valve Type Directional Control
- Mounting Base Mounted
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of W1413A1408W on Applied Automation is $72.25. Order now.
