9576K4001Z ROSS Controls Electronic Components
Part#:9576K4001Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series 5/2 Single Solenoid Valve, Normally Open, Ports (In-Out) 1/2" NPT, 110/120 VAC
Product Details
- Manual Override Non-locking
- Valve Body Material Die Cast Aluminum
- Power Consumption 3.6 VA holding on 50/60 Hz
- Weight (kg) 0.75
- Thread Type NPT
- Poppet/Spool Material Aluminum
- Seal Material Buna-N, Viton
- Length 1.43 in (36.5 mm)
- Return Spring
- Operating Pressure (bar) 1.5 to 10
- Outlet Pipe Size 1/2"
- Width 6.75 in (171.5 mm)
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Actuation Electrical
- Exhaust Pipe Size 1/2"
- Series 95
- Fluid Media Filtered Air
- Function 3/2 Single Solenoid
- Avg Cv 4.5
- Valve Type Directional Control
- Media Temperature (Celcius) 5 to 60
- Default Position Normally Open
- Length (mm) 36.5
- Construction Spool
- Ambient Temperature (Celcius) 5 to 60
- Connection EN 175301-803 Industrial Form B
- Width (mm) 171.5
- Duty Rating Continuous Duty
- Operating Pressure 22.5 to 150 psig (1.5 to 10 bar)
- Inlet Pipe Size 1/2"
- Height 2.91 in (74.0 mm)
- Mounting Inline/Manifold
- Media Temperature 41 to 140 F (5 to 60 C)
- Pilot Type Internal
- Weight 1.66 lb (0.75 kg)
- Application General
- Pilot Supply Minimum equal to or greater than inlet pressure
- Voltage 110/120 VAC
- Height (mm) 74
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
