9576K2901Z ROSS Controls Electronic Components
Part#:9576K2901Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series, Namur 3/2 Single Solenoid Valve, 1/4" NPT Ports, 110/120 VAC, EN (DIN)
Product Details
- Inlet Pipe Size 1/4"
- Duty Rating Continuous Duty
- Voltage 110/120 VAC
- Power Consumption 5.5 VA holding on 50/60 Hz
- Application General
- Default Position Normally Closed
- Ambient Temperature (Celcius) 5 to 60
- Width (mm) 29.5
- Mounting Inline
- Seal Material Buna-N
- Connection EN 175301-803 Industrial Form B
- Height (mm) 70.5
- Valve Standard Namur
- Poppet/Spool Material Stainless Steel
- Media Temperature 41 to 140 F (5 to 60 C)
- Outlet Pipe Size 1/4"
- Size 1/4"
- Operating Pressure 150 psig (10 bar)
- Return Spring
- Exhaust Pipe Size 1/4"
- Media Temperature (Celcius) 5 to 60
- Manual Override Non Locking
- Series 95
- Function 3/2 Single Solenoid
- Width 1.16 in (29.5 mm)
- Thread Type NPT
- Pilot Type Internal
- Avg Cv 1.3
- Operating Pressure (bar) 10
- Weight 0.80 lb (0.36 kg)
- Valve Type Directional Control
- Construction Spool
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Length (mm) 154.5
- Height 2.78 in (70.5 mm)
- Actuation Electrical
- Fluid Media Filtered Air
- Valve Body Material Aluminum
- Length 6.08 in (154.5 mm)
- Weight (kg) 0.36
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 9576K2901Z on Applied Automation is $68.25. Order now.
