9576K1002W ROSS Controls Electronic Components
Part#:9576K1002W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series 5/2 Double Solenoid Valve, Normally Open, Ports (In-Out) 1/8" NPT, 24 VDC
Product Details
- Outlet Pipe Size 1/8"
- Power Consumption 2.5 watts
- Valve Body Material Die Cast Aluminum
- Height 2.15 in (54.7 mm)
- Connection MICRO-MINI EN 175301-803
- Operating Pressure (bar) 1.5 to 10
- Pilot Type Internal
- Mounting Inline/Manifold
- Avg Cv 0.9
- Fluid Media Filtered Air
- Return Detented
- Width (mm) 159
- Inlet Pipe Size 1/8"
- Media Temperature 41 to 140 F (5 to 60 C)
- Actuation Electrical
- Exhaust Pipe Size 1/8"
- Ambient Temperature (Celcius) 5 to 60
- Poppet/Spool Material Aluminum
- Weight 0.62 lb (0.28 kg)
- Construction Spool
- Voltage 24 VDC
- Length 0.7 in (18.0 mm)
- Weight (kg) 0.28
- Thread Type NPT
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Length (mm) 18
- Height (mm) 54.7
- Series 95
- Duty Rating Continuous Duty
- Pilot Supply Minimum equal to or greater than inlet pressure
- Function 5/2 Double Solenoid
- Valve Type Directional Control
- Manual Override Non-locking
- Operating Pressure 22.5 to 150 psig (1.5 to 10 bar)
- Seal Material Buna-N, Viton
- Application General
- Media Temperature (Celcius) 5 to 60
- Default Position Normally Open
- Width 6.25 in (159.0 mm)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 9576K1002W on Applied Automation is $72.00. Order now.
