9576K1001Z ROSS Controls Electronic Components
Part#:9576K1001Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series 5/2 Single Solenoid Valve, Normally Open, Ports (In-Out) 1/8" NPT, 110/120 VAC
Product Details
- Return Spring
- Manual Override Non-locking
- Valve Body Material Die Cast Aluminum
- Height 2.15 in (54.7 mm)
- Valve Type Directional Control
- Fluid Media Filtered Air
- Poppet/Spool Material Aluminum
- Seal Material Buna-N, Viton
- Outlet Pipe Size 1/8"
- Avg Cv 0.9
- Operating Pressure 22.5 to 150 psig (1.5 to 10 bar)
- Weight 0.43 lb (0.20 kg)
- Construction Spool
- Duty Rating Continuous Duty
- Actuation Electrical
- Width 4.25 in (108.0 mm)
- Series 95
- Mounting Inline/Manifold
- Operating Pressure (bar) 1.5 to 10
- Height (mm) 54.7
- Application General
- Media Temperature 41 to 140 F (5 to 60 C)
- Pilot Supply Minimum equal to or greater than inlet pressure
- Weight (kg) 0.2
- Connection MICRO-MINI EN 175301-803
- Length 0.7 in (18.0 mm)
- Default Position Normally Open
- Inlet Pipe Size 1/8"
- Media Temperature (Celcius) 5 to 60
- Pilot Type Internal
- Voltage 110/120 VAC
- Thread Type NPT
- Ambient Temperature (Celcius) 5 to 60
- Function 3/2 Single Solenoid
- Width (mm) 108
- Exhaust Pipe Size 1/8"
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Length (mm) 18
- Power Consumption 3.6 VA holding on 50/60 Hz
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 9576K1001Z on Applied Automation is $48.25. Order now.
9576K1001Z Related Documents
Manufacturer warranty
9576K1001Z ROSS Controls
$48.25
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$48.25
$48.25 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Recently viewed products
Relevant products
FAQ
What is the price of 9576K1001Z?
Purchase the 9576K1001Z from Applied Automation at the price of $48.25. Order today.
Out if stock but available for backorder.
95 Series 5/2 Single Solenoid Valve, Normally Open, Ports (In-Out) 1/8" NPT, 110/120 VAC
