9574K2001W ROSS Controls Electronic Components
Part#:9574K2001W
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series 3/2 Single Solenoid Valve, Normally Open, Ports (In-Out) 1/4" NPT, 24 VDC
Product Details
- Thread Type NPT
- Operating Pressure (bar) 1.5 to 10
- Pilot Type Internal
- Width 4.33 in (110.0 mm)
- Return Spring
- Operating Pressure 22.5 to 150 psig (1.5 to 10 bar)
- Connection EN 175301-803 Industrial Form B
- Weight 0.70 lb (0.32 kg)
- Application General
- Power Consumption 2.5 watts
- Media Temperature (Celcius) 5 to 60
- Outlet Pipe Size 1/4"
- Width (mm) 110
- Exhaust Pipe Size 1/8"
- Fluid Media Filtered Air
- Valve Body Material Die Cast Aluminum
- Seal Material Buna-N, Viton
- Manual Override Non-locking
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Inlet Pipe Size 1/4"
- Height (mm) 67
- Mounting Inline/Manifold
- Media Temperature 41 to 140 F (5 to 60 C)
- Default Position Normally Open
- Length (mm) 26.5
- Construction Spool
- Ambient Temperature (Celcius) 5 to 60
- Function 3/2 Single Solenoid
- Weight (kg) 0.32
- Voltage 24 VDC
- Poppet/Spool Material Aluminum
- Avg Cv 1.3
- Series 95
- Valve Type Directional Control
- Actuation Electrical
- Height 2.63 in (67.0 mm)
- Duty Rating Continuous Duty
- Pilot Supply Minimum equal to or greater than inlet pressure
- Length 1.04 in (26.5 mm)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 9574K2001W on Applied Automation is $46.50. Order now.
9574K2001W Related Documents
Manufacturer warranty
9574K2001W ROSS Controls
$46.50
Your price can be lower.
Log in or Create account to check your discount
This part can be ordered
Select Qty:
$46.50
$46.50 each
This item may have a lead time. To ensure availability before placing your order, chat with our team—we'll confirm for you right away!
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
Your Safety, Our Priority.
Warranty
Manufacturer warranty
Responsive Customer Support
Got Questions? We've Got Answers!
Need more details?
Feel free to chat with us
Recently viewed products
Relevant products
FAQ
What is the price of 9574K2001W?
Purchase the 9574K2001W from Applied Automation at the price of $46.50. Order today.
Out if stock but available for backorder.
95 Series 3/2 Single Solenoid Valve, Normally Open, Ports (In-Out) 1/4" NPT, 24 VDC
