9556K3002 ROSS Controls Electronic Components
Part#:9556K3002
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series 5/2 Double Air Pilot Valve, Normally Closed, Ports (In-Out) 3/8" NPT
Product Details
- Default Position Normally Closed
- Function 5/2 Double Pilot
- Width (mm) 128.5
- Application General
- Media Temperature (Celcius) 5 to 60
- Fluid Media Filtered Air
- Outlet Pipe Size 3/8"
- Weight (kg) 0.49
- Valve Type Directional Control
- Pilot Supply Minimum equal to or greater than inlet pressure
- Exhaust Pipe Size 3/8"
- Manual Override Non-locking
- Poppet/Spool Material Aluminum
- Height 1.79 in (45.5 mm)
- Actuation Pneumatic
- Return Detented
- Width 5.06 in (128.5 mm)
- Construction Spool
- Operating Pressure 22.5 to 150 psig (1.5 to 10 bar)
- Length (mm) 32
- Series 95
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Seal Material Buna-N
- Length 1.25 in (32.0 mm)
- Pilot Type External
- Valve Body Material Die Cast Aluminum
- Height (mm) 45.5
- Mounting Inline/Manifold
- Ambient Temperature (Celcius) 5 to 60
- Media Temperature 41 to 140 F (5 to 60 C)
- Inlet Pipe Size 3/8"
- Thread Type NPT
- Operating Pressure (bar) 1.5 to 10
- Avg Cv 2.6
- Weight 1.07 lb (0.49 kg)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 9556K3002 on Applied Automation is $89.50. Order now.
