9553K2000 ROSS Controls Electronic Components
Part#:9553K2000
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
95 Series 3/2 Single Air Pilot Valve, Normally Closed, Ports (In-Out) 1/4" NPT
Product Details
- Construction Spool
- Pilot Type External
- Seal Material Buna-N
- Outlet Pipe Size 1/4"
- Actuation Pneumatic
- Operating Pressure 22.5 to 150 psig (1.5 to 10 bar)
- Poppet/Spool Material Aluminum
- Weight 0.51 lb (0.23 kg)
- Series 95
- Fluid Media Filtered Air
- Height 1.35 in (34.5 mm)
- Function 3/2 Single Pilot
- Pilot Supply Minimum equal to or greater than inlet pressure
- Length (mm) 26.5
- Mounting Inline/Manifold
- Media Temperature 41 to 140 F (5 to 60 C)
- Height (mm) 34.5
- Thread Type NPT
- Manual Override Non-locking
- Inlet Pipe Size 1/4"
- Length 1.04 in (26.5 mm)
- Default Position Normally Closed
- Media Temperature (Celcius) 5 to 60
- Width (mm) 71.5
- Valve Type Directional Control
- Ambient Temperature (Celcius) 5 to 60
- Exhaust Pipe Size 1/4"
- Return Spring
- Ambient Temperature 41 to 140 F (5 to 60 C)
- Valve Body Material Die Cast Aluminum
- Avg Cv 1.3
- Application General
- Operating Pressure (bar) 1.5 to 10
- Width 2.81 in (71.5 mm)
- Weight (kg) 0.23
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 9553K2000 on Applied Automation is $42.50. Order now.
