8076B6351Z ROSS Controls Electronic Components
Part#:8076B6351Z
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
SAE Size 500, 80 Series, 5/2 Single Solenoid Valve, Spool & Sleeve, Hardwire, 110/120 VAC
Product Details
- Series 80
- Manual Override Non-locking
- Power Consumption 87 VA inrush, 30 VA holding on 50/60 Hz
- Height 4.8 in (121 mm)
- Connection Hardwired
- Construction Spool & Sleeve
- Function 5/2 Single Solenoid
- Pilot Type Internal/External
- Ambient Temperature 40 to 120 F (4 to 50 C)
- Operating Pressure (bar) Vacuum to 10
- Length (mm) 76
- Poppet/Spool Material Stainless Steel
- Width (mm) 248
- Actuation Electrical
- Mounting Base Mounted
- Size 500
- Voltage 110/120 VAC
- Fluid Media Filtered air
- Operating Pressure Vacuum to 150 psig (10 bar)
- Pilot Supply Minimum equal to or greater than inlet pressure
- Valve Standard SAE
- Avg Cv 8.2
- Valve Body Material Cast Aluminum
- Return Spring
- Duty Rating Continuous Duty
- Width 9.80 in (248 mm)
- Default Position Normally Open
- Media Temperature 40 to 175 F (4 to 80 C)
- Height (mm) 121
- Weight (kg) 3.7
- Application General
- Ambient Temperature (Celcius) 4 to 50
- Length 3.0 in (76 mm)
- Seal Material Buna-N
- Valve Type Directional Control
- Media Temperature (Celcius) 4 to 80
- Weight 8.3 lb (3.7 kg)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 8076B6351Z on Applied Automation is $659.75. Order now.
