3623A2004 ROSS Controls Electronic Components
Part#:3623A2004
Manufacturer:ROSS Controls
Category:Electronic Components
Product Lifecycle:Active
Product description
36 Series, 3/2 Manual Lever Valve, Normally Open, Spring Return, Port (In-Out) 1/4", NPT, Port (Exhaust) 1/4" NPT
Product Details
- Return Spring
- Valve Type Directional Control
- Mounting Inline
- Series 36
- Default Position Normally Open
- Operating Pressure 5 to 150 psig (0.3 to 10 bar)
- Actuation Manual Lever
- Construction Poppet
- Function 3/2
- Media Temperature -30 to 175 F (-34 to 80 C)
- Weight 1.3 lb (0.6 kg)
- Ambient Temperature (Celsius) -34 to 80
- Thread Type NPT
- Inlet Pipe Size 1/4"
- Valve Body Material Cast Aluminum
- Fluid Media Filtered Air
- Length (mm) 87
- Height 3.2 in (81 mm)
- Height (mm) 81
- Exhaust Pipe Size 1/4"
- Lever Position Horizontal
- Length 3.44 in (87 mm)
- Application General
- Media Temperature (Celsius) -34 to 80
- Operating Pressure (bar) 0.3 to 10
- Width (mm) 183
- Ambient Temperature -30 to 175 F (-34 to 80 C)
- Weight (kg) 0.6
- Outlet Pipe Size 1/4"
- Avg Cv 1.2
- Width 7.19 in (183 mm)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 3623A2004 on Applied Automation is $152.75. Order now.
