PAXS0010 Red Lion Industrial Automation Components

PAXS0010 on Applied Automation
Red Lion

Part#:PAXS0010

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXS0010 is a dynamometer digital meter designed for strain gauge/load cell measurement applications. It features a 1/8 DIN (96x48mm) design with 14.2mm green digits and communication capability, making it suitable for a variety of industrial settings. The device operates on a supply voltage range of 85-250Vac, accommodating multiple standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. Part of the PAX series, it has dimensions of 1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95"), ensuring compatibility with standard panel cutouts. The PAXS0010 offers an IP65 NEMA 4X degree of protection, making it resistant to dust and water ingress. It features a 20Hz analog input sampling rate for real-time monitoring and includes 1 x analog input (-24...+24mV / -240...+240mV strain gauge input DC; 16-bits conversion) for precise measurement. Additionally, it is equipped with 3 x digital inputs (Sink/Source) for user inputs and 1 x analog output for retransmission, enhancing its versatility in automation applications.

Product Details

  • Main function
    Dynamometer (Digital)
  • Sub-range name
    PAX series
  • Primary brand
    Red Lion
  • Functions
    Strain gauge / load cell digital meter
  • Digital inputs
    3 x digital inputs (Sink/Source) (USER INPUT)
  • Degree of protection
    IP65 NEMA 4X
  • Product series / family name
    Process indicators
  • Display
    1 row x 5-digits red characters (14.2mm / 0.56" high) LED display
  • Frequency
    20Hz analog input sampling rate
  • Supply voltage (DC)
    11-36Vdc (12Vdc / 24Vdc)
  • Analog outputs
    1 x analog output (retransmission)
  • Order code / Manufacturer SKU
    PAXS0010
  • Design
    3 users inputs 1/8 DIN (96x48mm) 14.2mm red digits communication capability
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Analog inputs
    1 x analog input (-24...+24mV / -240...+240mV strain gauge input DC; 16-bits conversion)
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PAXS0010 on Applied Automation is $643.00. Order now.
