PAXP0110 Red Lion Industrial Automation Components
Part#:PAXP0110
Manufacturer:Red Lion
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
Red Lion PAXP0110 is a digital tachometer/rate meter from the PAX series, designed with 3 user inputs and conforms to a 1/8 DIN size, measuring 96mm in width and 48mm in height (3.80" x 1.95"). This unit offers a degree of protection rated at IP65 NEMA 4X, suitable for various industrial environments. It operates on a supply voltage range of 11-36Vdc, accommodating both 12Vdc and 24Vdc systems. The PAXP0110 features 1 digital input capable of handling frequencies up to 34kHz for counter functions, alongside 3 additional digital inputs that can function as either Sink or Source, catering to diverse user input requirements.
Product Details
- Primary brand Red Lion
- Display 1 row x 6-digits green characters (14.2mm / 0.56" high) LED display
- Digital inputs 3 x digital inputs (Sink/Source) (USER INPUT)
- Dimensions 1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
- Main function Meter (Digital)
- Product series / family name Process indicators
- Sub-range name PAX series
- Supply voltage (DC) 11-36Vdc (12Vdc / 24Vdc)
- Compliant with standard(s) CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
- Functions Process meter
- Order code / Manufacturer SKU PAXP0110
- Analog inputs 1 x analog input (0-20mA / 0-10Vdc; 16-bits conversion)
- Design 3 user inputs 1/8 DIN (96x48mm) 14.2mm green digits communication capability
- Degree of protection IP65 NEMA 4X
- Analog outputs 1 x analog output (retransmission)
- Frequency 20Hz analog input sampling rate
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
