PAXP0100 Red Lion Industrial Automation Components
Part#:PAXP0100
Manufacturer:Red Lion
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
Red Lion PAXP0100 is a digital tachometer/rate meter belonging to the PAX series, designed with 3 user inputs and conforms to a 1/8 DIN size, measuring 96mm in width and 48mm in height (approximately 3.80" x 1.95"). It operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. This part features a degree of protection rated at IP65 and NEMA 4X, ensuring its suitability for demanding environments. It is equipped with 1 digital input capable of handling frequencies up to 34kHz for counter functions, alongside 3 additional digital inputs that support both Sink and Source configurations for user input.
Product Details
- Display 1 row x 6-digits green characters (14.2mm / 0.56" high) LED display
- Functions Process meter
- Frequency 20Hz analog input sampling rate
- Product series / family name Process indicators
- Design 3 user inputs 1/8 DIN (96x48mm) 14.2mm green digits communication capability
- Primary brand Red Lion
- Supply voltage (AC) 85-250Vac (100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
- Digital inputs 3 x digital inputs (Sink/Source) (USER INPUT)
- Order code / Manufacturer SKU PAXP0100
- Main function Meter (Digital)
- Analog inputs 1 x analog input (0-20mA / 0-10Vdc; 16-bits conversion)
- Dimensions 1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
- Sub-range name PAX series
- Analog outputs 1 x analog output (retransmission)
- Degree of protection IP65 NEMA 4X
- Compliant with standard(s) CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PAXP0100 on Applied Automation is $411.00. Order now.
