PAXD0100 Red Lion Industrial Automation Components

PAXD0100 on Applied Automation
Red Lion

Part#:PAXD0100

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXD0100 is a dual process meter part of the PAX series, designed with a 1/8 DIN (96x48mm) form factor and features 14.2mm red digits for clear display, along with communication capabilities. It operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. The meter is equipped with one analog input supporting both current (-20...+20mA) and voltage (-10...+10Vdc) signals with a 16-bits conversion, three digital inputs (Sink/Source) for user input, and one analog output for retransmission purposes. It offers an analog input sampling rate between 5.3Hz and 105Hz. The PAXD0100 is designed to fit into a 1/8 DIN horizontal slot, with dimensions of W96mm x H48mm (3.80" x 1.95"), and is protected by an IP65 NEMA 4X rated enclosure, ensuring its suitability for various industrial environments.

Product Details

  • Primary brand
    Red Lion
  • Display
    1 row x 6-digits green characters (14.2mm / 0.56" high) LED display
  • Frequency
    20Hz analog input sampling rate
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Order code / Manufacturer SKU
    PAXD0100
  • Degree of protection
    IP65 NEMA 4X
  • Main function
    Meter (Digital)
  • Functions
    DC universal analog meter
  • Supply voltage (AC)
    85-250Vac (100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
  • Analog inputs
    1 x analog input (-200...+200μA / -2...+2mA / -20...+20mA / -200...+200mA / -2...+2A / -200...+200V / -2...+2V / -20...+20V / -300...+300V / 100Ω / 1kΩ / 10kΩ DC; 16-bits conversion)
  • Product series / family name
    Process indicators
  • Analog outputs
    1 x analog output (retransmission)
  • Sub-range name
    PAX series
  • Design
    3 user inputs 1/8 DIN (96x48mm) 14.2mm green digits communication capability
  • Digital inputs
    3 x digital inputs (Sink/Source) (USER INPUT)
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PAXD0100 on Applied Automation is $429.00. Order now.
