87690 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  712 g
• Series
  Transformators/Power Supplies
• Efficiency
  92.5% (3× 400 V AC); 91.8% (3× 480 V AC)
• Output current
  3.7 A (70 °C); 5.0 A (60 °C); 6.0 A (45 °C)
• Product article number of manufacturer
  87690
• Standards
  IEC 61010-2-201, EN 61204-3, EN 55011 B, EN 61000-3-2, SEMI F47
• Parallel usage/serial usage
  max. 3 units
• Output voltage
  24 V DC (SELV), ±1%; 24...28 V adjustable
• Input fuse (internal)
  3× 6.3 A (T)
• Mounting method
  DIN-rail mountable TH35 (EN 60715)
• Power Boost
  Iout N × 150% (min. 5 s)
• Protection
  IP20
• Spikes
  max. 50 mV ss/pp
• Temperature range
  -40...+70 °C, ...+70 °C derating (storage temperature -40...+85 °C)
• Unit protection
  short-circuit and overload protected, permanently by 20% (to 45 °C)
• Relative humidity
  5...95%, no condensation
• Ripple
  max. 20 mV eff/rms
• Inrush current after 1 ms
  max. 9.5 A (3× 500 V AC)
• Connection
  Push-In spring clamp terminals
• Dimensions H×W×D
  143×50×143 mm
Mains failure bridging time
min. 25 ms (3× 360 V AC); 5 A (24 V DC)
Frequency
50...60 Hz
LED display
LED (green): OK; LED (red): overload, overheating or short-circuit
Power factor
0.61 (3× 400 V AC)
Input voltage
3× 324...572 V AC/450...745 V DC
Input current
0.45 A (3× 360 V AC); 0.3 A (3×500 V AC)
