7000-12961-0000000 Murr Elektronik Cable Assemblies
Part#:7000-12961-0000000
Alt. Part#:7000-12962-0000000
Manufacturer:Murr Elektronik
Category:Cable Assemblies
Product Lifecycle:Active
Sep 6, 2026
Product description
7000-12961-0000000 Murrelektronik - M12 FEMALE 0° FIELD-WIREABLE SCREW TERM., 5-pol. max.0,75mm² 6-8mm
Product Details
- Weight 26.6 g
- Series Connector Systems
- Operating voltage max. 60 V AC/DC
- Compression gland M12 (SW18)
- Temperature range -40...+85 °C
- Product article number of manufacturer 7000-12961-0000000
- Locking of ports Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
- Rated surge voltage 1.5 kV
- Connection cross section max. 0.75 mm²
- Operating current per contact max. 4 A; max. 3 A (UL-Recognized)
- Operating voltage (only UL listed) max. 125 V AC/DC
- Material group III
- Sealing range (cable Ø) 6...8 mm
- Form 12961
- Over voltage category II
- Dimensions H×W×D 54×20×20 mm
- Protection IP67 inserted and tightened (EN 60529)
- Pollution Degree 3
- Material (housing) PA
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 7000-12961-0000000 on Applied Automation is $27.50. Order now.
