85383 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  680 g
• Series
  Transformators/Power Supplies
• Efficiency
  92.5% (3× 400 V AC); 91.8% (3× 480 V AC)
• Unit protection
  short-circuit and overload protected, permanently by 20% (to 45 °C)
• Input voltage
  3× 324...572 V AC/450...745 V DC
• Relative humidity
  5...95%, no condensation
• Input current
  0.45 A (3× 360 V AC); 0.3 A (3×500 V AC)
• Output current
  4.8 A (45 °C); 4.0 A (60 °C); 2.9 A (70 °C)
• Frequency
  50...60 Hz
• Output voltage
  30.5 V DC (SELV), ±1%; 30...32 V adjustable
• Inrush current after 1 ms
  max. 9.5 A (3× 500 V AC)
• Protection
  IP20
• Spikes
  max. 50 mV ss/pp
• Connection
  Push-In spring clamp terminals
• Ripple
  max. 20 mV eff/rms
• Mounting method
  DIN-rail mountable TH35 (EN 60715)
• Temperature range
  -40...+70 °C, ...+70 °C derating (storage temperature -40...+85 °C)
• Power factor
  0.61 (3× 400 V AC)
• Standards
  IEC 61010-2-201, EN 61204-3, EN 61000-3-2, SEMI F47
• Mains failure bridging time
  min. 20 ms (3× 360 V AC); 5 A (24 V DC)
Product article number of manufacturer
85383
Dimensions H×W×D
143×50×143 mm
LED display
LED (green): OK; LED (red): overload, overheating or short-circuit
Input fuse (internal)
3× 6.3 A (T)
Power Boost
Iout N × 150% (min. 5 s)
Parallel usage/serial usage
max. 3 units
