85164 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  700 g
• Series
  Transformators/Power Supplies
• Mounting method
  DIN-rail mountable TH35 (EN 60715)
• Input current
  2.9 A (115 V AC); 1.6 A (230 V AC)
• Output voltage
  24 V DC (SELV), ±1%; 22...28 V adjustable
• Parallel usage/serial usage
  max. 5 units/max. 2 units
• Standards
  IEC 61010-2-201, EN 61204-3, EN 55011 A
• Inrush current after 1 ms
  max. 37 A
• Dimensions H×W×D
  115×54×145 mm
• Product article number of manufacturer
  85164
• Efficiency
  87%
• Primary fusing external
  max. 10 A
• Relative humidity
  5...95%, no condensation
• Spikes
  max. 100 mV ss/pp
• Mains failure bridging time
  min. 14 ms (115 V AC); min. 80 ms (230 V AC)
• Output current
  7.5 A (+40 °C), 6 A (+55 °C)
• Ripple
  max. 20 mV eff/rms
• Frequency
  50...60 Hz
• LED display
  LED (green) for output voltage
• Unit protection
  short-circuit and overload protected
Temperature range
-25...+40 °C, ...+50 °C derating (storage temperature -25...+85 °C)
Input voltage
100...265 V AC
