85163 Murr Elektronik AC/DC Power Supplies

Name: 85163
Brand: Murr Elektronik
Price: 264.55 USD
Availability: BackOrder

Part#:85163

Category:AC/DC Power Supplies

Product Lifecycle:Active

Product description

85163 Murrelektronik - MCS-B POWER SUPPLY 1-PHASE, IN: 100-265VAC OUT: 24V/5ADC

Product Details

Weight
621.79 g
Series
Transformators/Power Supplies
Dimensions H×W×D
115×62×125 mm
Unit protection
short-circuit and overload protected
Primary fusing external
max. 10 A
Output current
5 A (+40 °C); 4 A (+55 °C)
Input voltage
100...265 V AC
Mounting method
DIN-rail mountable TH35 (EN 60715)
Frequency
50...60 Hz
Standards
IEC 61010-2-201, EN 61204-3, EN 55011 A
Inrush current after 1 ms
max. 30 A
Output voltage
24 V DC (SELV), ±1%; 22...28 V adjustable
Input current
2 A (110 V AC); 1.16 A (230 V AC)
LED display
LED (green) for output voltage
Spikes
max. 100 mV ss/pp
Relative humidity
5...95%, no condensation
Ripple
max. 20 mV eff/rms
Temperature range
-25...+40 °C, ...+50 °C derating (storage temperature -25...+85 °C)
Parallel usage/serial usage
max. 5 units/max. 2 units
Product article number of manufacturer
85163

Efficiency

86% (115 V AC); 87% (230 V AC)

Mains failure bridging time

min. 10 ms (110 V AC); min. 80 ms (230 V AC)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 85163 on Applied Automation is $264.55. Order now.
