85010 Murr Elektronik AC/DC Power Supplies

Product Details

• Weight
  2000 g
• Series
  Transformators/Power Supplies
• Output voltage
  48 V DC (SELV), ±1%; 48...56 V adjustable
• Spikes
  max. 100 mV ss/pp
• Input current
  3× 1.3 A
• Relative humidity
  5...95%, no condensation
• Frequency
  50...60 Hz
• Protection
  Varnished board
• Alarm output
  electronic relay max. 30 V DC/0.1 A, group alarm
• Product article number of manufacturer
  85010
• Efficiency
  92.3% (3× 360 V AC); 91% (3× 520 V AC)
• Mains failure bridging time
  min. 24 ms (400 V AC)
• Standards
  IEC 61010-2-201, EN 61204-3, EN 55022 B, EN 61000-3-2
• LED display
  LED (green): OK; LED (red): overload
• Unit protection
  short-circuit and overload protected
• Dimensions H×W×D
  132×113×136 mm
• Output current
  10 A (+55 °C); 8 A (+70 °C)
• Input voltage
  3× 324...572 V AC/480...745 V DC
• Temperature range
  -25...+70 °C (storage temperature -40...+85 °C)
• Ripple
  max. 50 mV eff/rms
Inrush current after 1 ms
max. 23 A
Power Boost
Iout N × 150% (min. 4 s)
Mounting method
DIN-rail mountable TH35 (EN 60715)
Primary fusing external
max. 3× 20 A
Connection
Screw terminals
Parallel usage/serial usage
max. 5 units/no
