7024-46041-5230750 Murr Elektronik Cable Assemblies

Product Details

• Weight
  641 g
• Series
  Connector Systems
• Form
  46041
• Approval (cable)
  UL (AWM-Style 22126/11558), CE conform
• AWG
  similar to AWG 20 (0.5 mm²); similar to AWG 24 (0.25 mm²)
• Test voltage
  3000 V
• Material group
  IEC 60664-1, category I
• Material
  PP
• Temperature range
  -40...+105 °C, depending on cable quality
• Single wire Ø (core)
  0.15 mm (0.5 mm²); 0.1 mm (0.25 mm²)
• Shield (Type)
  Copper braid
• Bend radius (fixed)
  5× outer Ø
• suitable for corrugated tube (internal Ø)
  without
• Material (contact carrier)
  PP, ice blue
• Color (jacket)
  pastel blue
• Torsion stress
  ±180°/m
• LED display
  no
• Material (gasket)
  EPDM
• Resistor (core)
  max. 39 Ω/km (0.5 mm²), max. 78 Ω/km (0.25 mm²); (20 °C)
• Outer-Ø (jacket)
  7.9 mm ±5%
Travel speed (C-track)
max. 3 m/s
Coding
A-coded
Mounting method
inserted, tightened
Material (wire)
Cu wire, bare
Material (jacket)
TPE-S
Bend radius (moving)
10× outer Ø
Operating voltage
max. 30 V AC/DC
Compression gland
M12 (SW14)
Pollution Degree
3
Cable weight [g/m]
82,5 g
Shield
yes
Temperature range (mobile)
-25...+105 °C
Rated surge voltage
0.8 kV
Protection
IP65, IP68, IP69K inserted and tightened (EN 60529)
Material (contact surface)
Au
Diameter (core)
4× 0.5 + 2× 0.25 mm²
Color/numbering of wires
(bl, wh, br, bk) + (gr, pk)
Nominal voltage
300 V AC
Acceleration (C-track)
max. 10 m/s²
Operating current per contact
max. 4 A
Locking material
Stainless steel 1.4404 (V4A)
Construction (core)
28× 0.15 mm (0.5 mm²); 32× 0.1 mm (0.25 mm²); (multi-strand wire class 6)
optical shield cover
min. 80%
No. of bending cycles (C-track)
max. 4 Mio. (25 °C)
Locking of ports
Screw thread (M12×1 mm) recommended torque 0.6 Nm, self-securing
Material (contact)
Copper alloy
Material (wire isolation)
PP
Jacket Color
gray
Product article number of manufacturer
7024-46041-5230750
No. of poles
6
Standards
DIN EN 61076-2-101 (M12), FDA conform
Cable identification
523
Wire-Ø incl. isolation
1.5 mm ±5% (0.5 mm²); 1.4 mm ±5% (0.25 mm²)
Temperature range (fixed)
-40...+105 °C
Cable length
7,5 m
No. of torsion cycles
max. 2 Mio. (25 °C)
